Liansheng Series Professional Indoor Tennis Court Tents

Let professional tennis break through the limitations of seasons and weather!

Core strengths
International standard arena size
Designed in strict accordance with ITF standards, the clear height is ≥ 9 meters, which perfectly meets the needs of professional competitions and training, and there is no barrier-free swing space

️ All-weather sports environment
It uses 850g/m² high-strength PVC tarpaulin (light transmittance of 12%), with a professional ventilation system, to eliminate condensation and achieve all-weather training in rain, snow and heat

⚡ Rapid response build
Modular components, 1,000 square meters of standard site construction can be completed in 15 days, saving 80% of time compared with traditional buildings

Professional sports lighting
Pre-installed IP65 protection LED arena lighting system (500lux adjustable), no glare, no strobe, TV broadcast grade light effect

Detailed product description
"Liansheng" is a professional-grade indoor training venue solution for tennis clubs, sports centers and educational institutions. We understand the demanding requirements of tennis on space clearance, floor flatness and light environment, which is why we have launched this innovative product that combines professionalism and economic efficiency.

The tent uses a reinforced aluminum alloy main structure, and the load distribution is calculated through finite element analysis to ensure that there is no need for intermediate support columns when spanning up to 40 meters. The ceiling is made of specially selected UV-resistant PVC material, which effectively blocks 85% of infrared heat while maintaining suitable natural diffused light, and with a patented convective ventilation system, it can always keep the indoor air fresh and free of condensation.

The venue can fully accommodate standard doubles arenas (36.6m×18.3m), rest areas and training walls, and all lighting lines and equipment hanging points are embedded to eliminate potential safety hazards. We also provide professional sports flooring solutions (acrylic/plastic flooring) to truly achieve a professional experience of "carrying and fighting".

Technical specifications
Project specifications
Main structure High-strength 6082-T6 aluminum alloy
Covering material 850g/m²PVC tarpaulin (anti-UV/self-cleaning)
Standard span 20m/30m/40m
Eave height 4-6m (side wall) 3-5m (top arch)
Headroom ≥9m (center point)
Wind resistance class 10 (depending on configuration)
Snow load 0.75-1.5kN/m²
Optional system Constant temperature and humidity system, anti-glare lighting, intelligent ventilation
Applicable Institutions
Professional Tennis Club - Expand your training grounds and make a profit all year round

International Schools - Build high-standard campus sports facilities

Resort - Create high-end sports and leisure packages

Sports Center - Rapidly expands to host events

Municipal project - construction of sports facilities for the benefit of the people

Service support
✅ Free site planning - CAD layout drawings and sunlight analysis are provided
✅ One-stop delivery - including basic treatment/tent/flooring/lighting all-inclusive service
✅ Event Guarantee - Technical team is dispatched to provide on-site support during major events
✅ Financial Solutions - Financial leasing and installment services are provided
✅ Warranty system - 10 years warranty for the main structure and 5 years warranty for tarpaulin
