Facing urgent storage needs or expanding operational space? The Liansheng Titan Series 20m x 50m Storage Marquee delivers a robust, cost-effective, and immediate solution. This colossal 1,000 sqm clear-span shelter is engineered for performance and durability, providing unparalleled protection for your valuable assets, machinery, and inventory against the elements.
Ideal for construction sites, manufacturing plants, logistics hubs, and agricultural storage, the Titan Series combines industrial-grade strength with rapid deployment. Its versatile design ensures a reliable, large-scale temporary or semi-permanent structure that can be customized to meet your specific operational requirements.
| Quantity: | |
|---|---|
Tent
LIANSHENG
The 20-meter width and 50-meter length provide a massive 1,000 square meters of column-free interior space. This allows for maximum storage density, easy movement of large equipment like forklifts, and flexible racking or shelving layouts without any obstructions.
Superior Frame Structure: The primary framework is constructed from high-tensile, hot-dip galvanized steel, offering exceptional strength and corrosion resistance, ensuring a long service life even in harsh industrial environments.
Robust Cladding: The marquee is covered with 850g/sq㎡ or 1100g/sq㎡ high-density PVC-coated fabric, featuring excellent tensile strength, waterproofing (>3000mm water column), and UV resistance. A fire-retardant (B1) option is available.
Engineered for Safety: The structure is designed to withstand strong winds (up to 100-120 km/h) and significant snow loads (customizable up to 1.0 kN/㎡), providing peace of mind during severe weather.
Effortless Expansion: The modular system allows for easy extension in length or connection of multiple units to create even larger storage complexes.
Tailored Access & Layout: Configure the marquee with various access points:
Large Side Doors: For full-height container or truck access.
Double-End Doors: For easy throughput of vehicles and machinery.
Roll-up Side Panels: For wide, open access to specific sections.
Ventilation & Environment: Options include roof vents, side ventilation panels, and the integration of extraction fans to maintain air quality and reduce moisture buildup.
Achieve a massive amount of covered space in a fraction of the time and cost of a permanent structure. All components are pre-fabricated for efficient assembly by a professional team, minimizing downtime and getting your operations under cover faster.
| Category | Specification |
|---|---|
| Product Series | Liansheng · Titan Series |
| Standard Size | 20m (w) x 50m (l) |
| Total Area | 1,000 sqm |
| Eave Height | 4m, 5m, 6m (Customizable) |
| Frame Material | High-Tensile Hot-Dip Galvanized Steel |
| Cover Material | 850g/1100g PVC Fabric (Fire-Retardant B1 Optional) |
| Wind Resistance | Up to 100-120 km/h (Subject to anchoring) |
| Snow Load | Up to 1.0 kN/㎡ (Design dependent) |
| Base Frame & Anchoring | Heavy-duty base frame with ground anchors/concrete foundations |
| Optional Features | Various Door Types, Roof Vents, Side Vents, Skylight Panels, Insulated Liners, Partition Walls |
Construction & Civil Engineering: On-site material storage, equipment shelter, temporary workshops.
Logistics & Warehousing: Seasonal inventory overflow, temporary distribution centers, raw material storage.
Manufacturing & Industry: Additional production space, machinery weather protection, bulk item storage.
Agriculture: Harvest storage, machinery sheds, livestock feed protection.
Emergency & Disaster Relief: Temporary warehousing for supplies and equipment.
We provide end-to-end support for your project:
Free Consultation & Custom Design: Tailoring the solution to your exact site and needs.
Professional Installation: Expert teams ensure safe and correct assembly.
Global Shipping & Logistics: Reliable delivery of your marquee system anywhere.
After-Sales Support: Comprehensive guidance and spare parts availability.
Ready to solve your storage challenges?
Contact us today for a free, no-obligation quote and preliminary layout design.
Liansheng Tents: Building Your Space, Securing Your Assets.
